MULTIFUNCTIONAL ELECTRONIC DESCALING INSTRUMENT

MULTIFUNCTIONAL ELECTRONIC DESCALING INSTRUMENT

MULTIFUNCTIONAL ELECTRONIC DESCALING INSTRUMENT

Categories	WATER CONTROL VALVE
Brand	KRV
Model	DN40-DN200
Update Time	2021-09-20

Detail Information

Main technical parameters

1. Input power: 220 V / 50 Hz

2. Suitable water quality: total hardness ≤ 1000mg / L, water temperature ≤ 90 ℃

The nominal pressure is 1.0MPa and 1.6Mpa, and the flow rate is ≤ 2.8m/s

3. Function: descaling rate ≥ 97%; antiscaling rate ≥ 97%; sterilization rate ≥ 95%

125 mm / A; alga killing rate ≥ 97%; effective time ≥ 0

Drawing of multifunctional electronic descaling instrument

Main connection dimensions

Specifications		D	D1	D0	L	d	h	weight		power	Maximum flow
mm	in	D	D1	D0	L	d	h	PN1.0MPa	PN1.6MPa	power	Maximum flow
40	1.5	145	110	48	150	25	110	18	18	30	12
50	2	160	125	60	450	25	110	19	19	30	19
65	2.5	150	145	76	450	25	110	21	21	30	32
80	3	195	160	86	500	25	110	21.5	21.5	30	50
100	4	215	180	108	500	40	130	89	87	30	80
125	5	145	210	133	500	40	160	127	132	30	125
150	6	280	240	159	600	50	200	172	180	50	180
200	8	335	295	219	600	50	230	259	278	50	320
